Cooling Piston Compressor
Cooling Piston Compressor
Cooling Piston Compressor cooling systems specially engineered to deliver powerful and reliable cooling in extremely hot climates. Designed to operate efficiently even in high ambient temperatures, these systems maintain consistent performance while ensuring optimal energy efficiency. Equipped with advanced rotary compressor technology, they provide faster cooling, smoother operation, and improved durability. Built with robust components and smart airflow design, Cooling Piston Compressor cooling systems offer dependable performance, long-lasting reliability, and superior comfort for residential and commercial environments, even during the hottest summer conditions.
Type
T3, Cooling only
Rated T1 Cooling Capacity (Btu/h)
19000
ESMA Cooling Capacity (Btu/h)
15700
Rated Input Cooling (W)
2000 / 2310
Moisture Removal (L/h)
1.8
Air Circulation Super (m3/h)
1050
EER For Cooling (W/W)
2.75 / 2.08
Refrigerant (Type/Kg)
R22
I/U Noise Level High (dB(A))
42
O/U Noise Level (dB(A))
56
Power Supply (Voltage/Frequency)
220–240V~, 50Hz
Rated Current Cooling (A)
9.3 / 10.6
LRA (A)
51.3
Compressor Type
Reciprocating
Compressor MFG
KK – Made In Thailand
Compressor Model No
AW5524EK
Capacity (W)
6140
Input (W)
2089
Rated Current (RLA) A
9.64
Indoor Fan Motor Voltage, Frequency (V,Hz)
1, 208–240V~, 50Hz
Model
DG13B2–07
Power Supply (V)
12V DC
Output (W)
4
Expansion Device
Throttling Pipe
Connecting Pipe Liquid Diameter (inch)
1/4
Connecting Pipe Gas Diameter (inch)
1/2
Connecting Pipe Connecting Cable Diamater
3×1.5 mm²
Net Dimensions Indoor (mm)
960×315×235
Net Dimensions Outdoor (mm)
860×650×310
Net Weight Indoor (Kg)
12.5
Net Weight Outdoor (Kg)
51.5
Packing Dimensions Indoor (mm)
1022×380×302
Packing Dimensions Outdoor (mm)
995×420×720
Gross Weight Indoor (Kg)
14.5
Gross Weight Outdoor (Kg)
58.5
Loading Capacity (40' HC)
160
Type
T3, Cooling only
Rated T1 Cooling Capacity (Btu/h)
26000
ESMA Cooling Capacity (Btu/h)
20130
Rated Input Cooling (W)
2465 / 2840
Moisture Removal (L/h)
-
Air Circulation Super (m3/h)
1200
EER For Cooling (W/W)
2.75 / 2.08
Refrigerant (Type/Kg)
R22
I/U Noise Level High (dB(A))
45
O/U Noise Level (dB(A))
57
Power Supply (Voltage/Frequency)
220–240V~, 50Hz
Rated Current Cooling (A)
11.6 / 12.9
LRA (A)
73
Compressor Type
Reciprocating
Compressor MFG
KK – Made In Thailand
Compressor Model No
AW5530EK 65H – A1
Capacity (W)
7327
Input (W)
2498
Rated Current (RLA) A
12
Indoor Fan Motor Voltage, Frequency (V,Hz)
1, 208–240V~, 50Hz
Model
DG13B2–07 (30)
Power Supply (V)
12V DC
Output (W)
4
Expansion Device
Throttling Pipe
Connecting Pipe Liquid Diameter (inch)
1/4
Connecting Pipe Gas Diameter (inch)
5/8
Connecting Pipe Connecting Cable Diamater
3×2.5 mm²
Net Dimensions Indoor (mm)
1131×235×315
Net Dimensions Outdoor (mm)
995×720×420
Net Weight Indoor (Kg)
14.5
Net Weight Outdoor (Kg)
57
Packing Dimensions Indoor (mm)
1220×310×400
Packing Dimensions Outdoor (mm)
995x420x720
Gross Weight Indoor (Kg)
17
Gross Weight Outdoor (Kg)
64
Loading Capacity (40' HC)
150
Type
T3, Cooling only
Rated T1 Cooling Capacity (Btu/h)
32000
ESMA Cooling Capacity (Btu/h)
24907
Rated Input Cooling (W)
3030 / 3400
Moisture Removal (L/h)
-
Air Circulation Super (m3/h)
1680
EER For Cooling (W/W)
2.9 / 2.15
Refrigerant (Type/Kg)
R22
I/U Noise Level High (dB(A))
50
O/U Noise Level (dB(A))
60
Power Supply (Voltage/Frequency)
220–240V~, 50Hz
Rated Current Cooling (A)
13.6 / 15.2
LRA (A)
85
Compressor Type
Reciprocating
Compressor MFG
KK – Made In Thailand
Compressor Model No
AW5535EK
Capacity (W)
8617
Input (W)
2910
Rated Current (RLA) A
14.7
Indoor Fan Motor Voltage, Frequency (V,Hz)
1, 208–240V~, 50Hz
Model
24BYJ48
Power Supply (V)
12V DC
Output (W)
4
Expansion Device
Capillary
Connecting Pipe Liquid Diameter (inch)
3/8
Connecting Pipe Gas Diameter (inch)
5/8
Connecting Pipe Connecting Cable Diamater
4×1.0 mm²
Net Dimensions Indoor (mm)
1280×345×250
Net Dimensions Outdoor (mm)
1050×500×890
Net Weight Indoor (Kg)
19.5
Net Weight Outdoor (Kg)
64
Packing Dimensions Indoor (mm)
1385×435×325
Packing Dimensions Outdoor (mm)
1050×500×890
Gross Weight Indoor (Kg)
23
Gross Weight Outdoor (Kg)
75
Loading Capacity (40' HC)
104
Type
T3, Cooling only
Rated T1 Cooling Capacity (Btu/h)
37000
ESMA Cooling Capacity (Btu/h)
30366
Rated Input Cooling (W)
3650 / 4280
Moisture Removal (L/h)
-
Air Circulation Super (m3/h)
1680
EER For Cooling (W/W)
2.9 / 2.15
Refrigerant (Type/Kg)
R22
I/U Noise Level High (dB(A))
50
O/U Noise Level (dB(A))
60
Power Supply (Voltage/Frequency)
220–240V~, 50Hz
Rated Current Cooling (A)
17.6 / 19.5
LRA (A)
85
Compressor Type
Reciprocating
Compressor MFG
KK – Made In Thailand
Compressor Model No
AW5542E
Capacity (W)
10522
Input (W)
3550
Rated Current (RLA) A
17
Indoor Fan Motor Voltage, Frequency (V,Hz)
1, 208–240V~, 50Hz
Model
DG13B1–01
Power Supply (V)
12V DC
Output (W)
4
Expansion Device
Throttling Pipe
Connecting Pipe Liquid Diameter (inch)
3/8
Connecting Pipe Gas Diameter (inch)
3/4
Connecting Pipe Connecting Cable Diamater
4×1.0 mm²
Net Dimensions Indoor (mm)
1280×345×250
Net Dimensions Outdoor (mm)
1050×500×890
Net Weight Indoor (Kg)
19.5
Net Weight Outdoor (Kg)
68
Packing Dimensions Indoor (mm)
1385×435×325
Packing Dimensions Outdoor (mm)
1050×500×890
Gross Weight Indoor (Kg)
23
Gross Weight Outdoor (Kg)
79
Loading Capacity (40' HC)
104
Features
Independent
Dehumidifier
Noise
Reduction
Easy Cleaning
High Density
Filter
Soft Touch
Start
Features
Energy Saving
Designed to consume minimal power, reducing your electricity bills without compromising performance.
Quiet Operation
Operates at a low noise level, ensuring a peaceful environment for work or rest.
Smart Wi-Fi
Allows users to control the AC remotely using a smartphone app or voice assistants like Alexa.
Turbo Cooling
Instant cooling by operating the AC at maximum capacity for a short period, Cools the room quickly.
Experience year-round comfort with advanced, energy-efficient air conditioning systems designed to deliver powerful performance and dependable reliability. Built with high-quality components and modern innovation, these systems create a consistently comfortable indoor environment in homes, offices, and commercial spaces.
Specifications
Cooling Performance
- Cooling Capacity: 18,000 BTU/h
- Cooling Area Coverage: Up to 180 sq. ft.
- Compressor Type: Rotary/Inverter
- Cooling Technology: Fast Cooling, Turbo Mode
Power & Energy Efficiency
- Power Supply: 220-240V, 50Hz
- Rated Power Input: 1500W
- Energy Efficiency Ratio (EER): 3.5
- Star Rating: 5-Star (BEE Certified)
- Annual Power Consumption: 1200 kWh
Dimensions & Weight
- Indoor Unit Dimensions (WxHxD): 900 x 300 x 220 mm
- Outdoor Unit Dimensions (WxHxD): 850 x 550 x 300 mm
- Weight (Indoor/Outdoor): 12 kg / 35 kg
Additional Information
- Warranty: 1 Year on Product, 10 Years on Compressor
- Included Accessories: Remote, Installation Kit, User Manual
- Country of Manufacture: Japan/China/India
Bringing happiness and comfort to every customer through high-quality air conditioning solutions designed for reliable performance and superior cooling. Our systems combine advanced technology, energy efficiency, and durable design to create a refreshing indoor environment, ensuring consistent comfort and satisfaction in homes and workplaces.
Reviews
7.5
Excellent product!
This AC is powerful, quiet, and smart—perfect for anyone who wants cooling with convenience. Highly recommend!
Powerful, quiet, and smart AC!
I love this air conditioner! It cools fast, runs quietly, and saves energy. The Wi-Fi control is super handy, letting me adjust settings from my phone.
It could be better!
It cools quickly, runs quietly, and saves energy, making it a solid upgrade from my old AC.
