Diamond Series – Piston
Diamond Series – Piston
Diamond Series – Piston AC units are engineered for high-capacity cooling with exceptional strength and performance. Powered by advanced piston compressor technology, these systems deliver powerful and consistent cooling, making them ideal for demanding environments and high-temperature conditions. Designed with durable components and precision engineering, the Diamond Series – Piston ensures reliable operation and long-lasting performance.
T1 Cooling Capacity
1.5 Ton
Climate Type
T3
T3 EER for Cooling (Btu/h)/W
10.54
Cooling Power (kW)
1.71kW
Cooling Current (A)
6.8A
Max Power Input (kW)
2.60kW
Max Input Current (A)
13.5A
Air Volume (m³/h)
1000m³/h
Power Supply
220–240V~/50Hz
Max High Pressure (MPa)
3.20MPa
Max Suction Pressure (MPa)
0.8MPa
Inside Noise Level (dB(A))
47dB(A)
Outside Noise Level (dB(A))
57dB(A)
Compressor Type
Reciprocating
Compressor MFG
COPELAND
Compressor Model
CR22K6M-PF1-101MM
Indoor Unit Dimensions (mm)
1082×330×233
Outdoor Unit Dimensions (mm)
830×660×315
Net Weight Indoor Unit (kg)
14kg
Net Weight Outdoor Unit (kg)
54kg
Gross Weight Indoor Unit (kg)
16kg
Gross Weight Outdoor Unit (kg)
58kg
Electric Shock Prevention
Class I
Waterproof Class Indoor
IPX0
Waterproof Class Outdoor
IPX4
Refrigerant
R22
Charge (kg)
1.4kg
Loading Capacity (40’ HC)
160
T1 Cooling Capacity
2 Ton
Climate Type
T3
T3 EER for Cooling (Btu/h)/W
10.44
Cooling Power (kW)
2.30kW
Cooling Current (A)
9.3A
Max Power Input (kW)
3.30kW
Max Input Current (A)
16A
Air Volume (m³/h)
1250m³/h
Power Supply
220–240V~/50Hz
Max High Pressure (MPa)
3.20MPa
Max Suction Pressure (MPa)
0.8MPa
Inside Noise Level (dB(A))
48dB(A)
Outside Noise Level (dB(A))
59dB(A)
Compressor Type
Reciprocating
Compressor MFG
COPELAND
Compressor Model
CR30K6M-PF1-101MM
Indoor Unit Dimensions (mm)
1082×330×233
Outdoor Unit Dimensions (mm)
830×660×315
Net Weight Indoor Unit (kg)
14kg
Net Weight Outdoor Unit (kg)
56kg
Gross Weight Indoor Unit (kg)
17kg
Gross Weight Outdoor Unit (kg)
61kg
Electric Shock Prevention
Class I
Waterproof Class Indoor
IPX0
Waterproof Class Outdoor
IPX4
Refrigerant
R22
Charge (kg)
1.45kg
Loading Capacity (40’ HC)
150
Features
Independent
Dehumidifier
Noise
Reduction
Easy Cleaning
High Density
Filter
Soft Touch
Start
Experience year-round comfort with advanced, energy-efficient air conditioning systems designed to deliver powerful performance and dependable reliability. Built with high-quality components and modern innovation, these systems create a consistently comfortable indoor environment in homes, offices, and commercial spaces.
Specifications
Cooling Performance
- Cooling Capacity: 18,000 BTU/h
- Cooling Area Coverage: Up to 180 sq. ft.
- Compressor Type: Rotary/Inverter
- Cooling Technology: Fast Cooling, Turbo Mode
Power & Energy Efficiency
- Power Supply: 220-240V, 50Hz
- Rated Power Input: 1500W
- Energy Efficiency Ratio (EER): 3.5
- Star Rating: 5-Star (BEE Certified)
- Annual Power Consumption: 1200 kWh
Dimensions & Weight
- Indoor Unit Dimensions (WxHxD): 900 x 300 x 220 mm
- Outdoor Unit Dimensions (WxHxD): 850 x 550 x 300 mm
- Weight (Indoor/Outdoor): 12 kg / 35 kg
Additional Information
- Warranty: 1 Year on Product, 10 Years on Compressor
- Included Accessories: Remote, Installation Kit, User Manual
- Country of Manufacture: Japan/China/India
Bringing happiness and comfort to every customer through high-quality air conditioning solutions designed for reliable performance and superior cooling. Our systems combine advanced technology, energy efficiency, and durable design to create a refreshing indoor environment, ensuring consistent comfort and satisfaction in homes and workplaces.
